Mitsubishi Ranges 22 kVA Diesel Generator
Brand:
Depco PowerItem NO.:
DPK-DM-22Frequency(Hz):
50Phase:
3Voltage(V):
380Engine:
MitsubishiEngine Model:
S4Q2PRP (kW):
16PRP (kVA):
20ESP (kW):
18ESP (kVA):
22Arrangement:
4LGovernor:
MechanicalSilent 18kw/22kva Mitsubishi Diesel Generator S4Q2
Product Introduce:
Mitsubishi diesel generator is one of the world top famous engines and widely acceptable all over the world.
We have all series from 17kva to 3788kva.
Application fields:
Diesel generator are used in any situation where a reliable backup power source is necessary to maintain continuity of operations.
Advantage of our Mitsubishi diesel generator :
The power range of SW type ultra-quiet unit covers 13-800kVA, and the noise level is higher than standard model designs.
1:The air inlet channel adopts directional design;
2:Extend the exhaust channel to reduce noise;
3:Equipped with resistance and resistance composite muffler;
4:Exhaust system
Exhaust hose connection design absorbs vibration of exhaust system components.
Equipped with an impedance and resistance composite high-efficiency silencer, reducing noise.
Optimize the direction of the exhaust pipe to achieve noise reduction.
Product Parameters:
| Details Generator Set | GenSet Model | DPK-DM-22 | Type | Silent |
| Frequency (Hz) | 50 | Speed (rpm) | 1500 | |
| Phase | 3 | Rated voltage | 380V | |
| Prime output | 16kW/20kVA | Standby output | 18kW/22kVA | |
| Cylinder | 4 | Cooling system | Water | |
| N.W (kg) | 498 | Size (L*W*H)mm | 1700*740*940 | |
| Fuel Con.(L/H) | 4.95 | Fuel capacity tank | 64 L | |
| Running time (H) | 8 | Sound decibel | 70DB-75DB | |
| Details Engine | Brand | Mitsubishi | ||
| Model | S4Q2 | Fuel | Diesel | |
| Cylinder | 4 | Cooling system | Water-cooling | |
| Cylider arrangemant | IN-LINE | Bore and Stroke(mm) | 88 X 103 | |
| Cyle | 4 Staoke | Compression ratio | 22.0:1 | |
| Governor | Mechanical | Displacement(L) | 2.505 | |
| Details Alternator | Brand | Depco, Stamford, Leroy Somer, Mecc Alte | ||
| Model | DPC184E/PI 144D/S0L2-M1/TAL-A40-F/LSA 40 M5/ECP28 M4C | |||
| No.of bearings | 1 | Insulation class | H | |
| Wires | 12 | Ingress protection | IP23 | |
| Excitation system | Shunt | Volrage | ±1% | |
