Mitsubishi Ranges 44 kVA Diesel Generator
Brand:
Depco PowerItem NO.:
DPK-DM-44Frequency(Hz):
50Phase:
3Voltage(V):
380Engine:
MitsubishiEngine Model:
S4S-DTPRP (kW):
32PRP (kVA):
40ESP (kW):
35ESP (kVA):
44Arrangement:
4LGovernor:
MechanicalSilent 35kw/44kva Mitsubishi Diesel Generator S4S-DT
Product Introduce:
Mitsubishi diesel generator is one of the world top famous engines and widely acceptable all over the world.
We have all series from 17kva to 3788kva.
Application fields:
Diesel generator are used in any situation where a reliable backup power source is necessary to maintain continuity of operations.
Advantage of our Mitsubishi diesel generator :
The power range of SW type ultra-quiet unit covers 13-800kVA, and the noise level is higher than standard model designs.
1:The air inlet channel adopts directional design;
2:Extend the exhaust channel to reduce noise;
3:Equipped with resistance and resistance composite muffler;
4:Exhaust system
Exhaust hose connection design absorbs vibration of exhaust system components.
Equipped with an impedance and resistance composite high-efficiency silencer, reducing noise.
Optimize the direction of the exhaust pipe to achieve noise reduction.
Product Parameters:
| Details Generator Set | GenSet Model | DPK-DM-44 | Type | Silent |
| Frequency (Hz) | 50 | Speed (rpm) | 1500 | |
| Phase | 3 | Rated voltage | 380V | |
| Prime output | 32kW/40kVA | Standby output | 35kW/44kVA | |
| Cylinder | 4 | Cooling system | Water | |
| N.W (kg) | 540 | Size (L*W*H)mm | 1980*800*1150 | |
| Fuel Con.(L/H) | 9.14 | Fuel capacity tank | 85 L | |
| Running time (H) | 8 | Sound decibel | 70DB-75DB | |
| Details Engine | Brand | Mitsubishi | ||
| Model | S4S-DT | Fuel | Diesel | |
| Cylinder | 4 | Cooling system | Water-cooling | |
| Cylider arrangemant | IN-LINE | Bore and Stroke(mm) | 94 X 120 | |
| Cyle | 4 Staoke | Compression ratio | 22.0:1 | |
| Governor | Mechanical | Displacement(L) | 3.331 | |
| Details Alternator | Brand | Depco, Stamford, Leroy Somer, Mecc Alte | ||
| Model | DPC184J/PI 144J/S1L2-N1/TAL-A42-F/LSA 42.3 S5/ECP32 2S4C | |||
| No.of bearings | 1 | Insulation class | H | |
| Wires | 12 | Ingress protection | IP23 | |
| Excitation system | Shunt | Volrage | ±1% | |
